Custom Red Single Lifting Mast Climbing Work Platform For Building Cleaning Maintenance

Custom Red Single Lifting Mast Climbing Work Platform For Building Cleaning MaintenanceProduct Description

Technical data of our mast climbing platform:

SCP400/30S:
1) Max. Length: 30m
2) Rated lifting speed: 6m/min
3) Basic width: 1.5m
4) Max. Width: 2.7m
5) Motor power: 2 x 2 x 3kW
6) Max. Unattached height: 3m
7) Max. Erection height (m): 150m
8) Interval distance of tie-in: 3-9m
8) Weight of main unit: 1, 000kg
9) I type platform section length: 1.22m
10) Size of mast section (L x W x H): 650 x 650 x 1, 508mm

SCP200/12D:
1) Max. Length: 12m
2) Rated lifting speed: 6m/min
3) Basic width: 1.5m
4) Max. Width: 2.7m
5) Motor power: 2 x 3kW
6) Max. Unattached height: 3m
7) Max. Erection height (m): 150m
8) Interval distance of tie-in: 3-9m
9) Weight of main unit: 1, 000kg
10) I type platform section length: 1.22m
11) Size of mast section (L x W x H): 650 x 650 x 1, 508mm

SCP230/9D:
1) Max. Length: 9m
2) Rated lifting speed: 8m/min
3) Basic width: 1.5m
4) Max. Width: 2.7m
5) Motor power: 2 x 3kW
6) Max. Unattached height: 12m
7) Max. Erection height (m): 150m
8) Interval distance of tie-in: 3-7.5m
9) Weight of main unit: 600 kg
10) I type platform section length: 1.5m
11) II type platform section length: 0.85m
12) Size of mast section (L x W x H): 550 x 550 x 1, 508mm

Welcome to visit our factory and send inquiry to sales003@chinaketong.cn

After-sales service system to ensure each end-user keep moving always ,please set your heart at rest to cooperate with us .

window cleaning platform

suspension cradle

Custom Red Single Lifting Mast Climbing Work Platform For Building Cleaning Maintenance Images
